T34-76 hexagonal turret 1-25scale
PITERPANZER
Visit this Community
Gdańsk, Poland
Joined: September 11, 2005
KitMaker: 314 posts
Armorama: 311 posts
Posted: Sunday, August 12, 2018 - 03:02 AM UTC
Mark constructive criticism is good every time before finish project.
This turret based on drawings from T34 Mitical weapon by Michulec.
I did the built report parallel on 1-25saf.com but unfortunately all pics from imageshack are gone.
MCR
Visit this Community
Arizona, United States
Joined: July 15, 2004
KitMaker: 448 posts
Armorama: 391 posts
Posted: Saturday, August 11, 2018 - 03:30 AM UTC
Not to be too critical, but the turret seems somewhat undersized? From the photos it's almost certainly too narrow. It's also appears to be missing the side vision ports.
Do you have better photos of it?

Mark
PITERPANZER
Visit this Community
Gdańsk, Poland
Joined: September 11, 2005
KitMaker: 314 posts
Armorama: 311 posts
Posted: Friday, August 10, 2018 - 07:25 PM UTC
Some pics from progress and use new resin parts early commander cupola, burnt out road wheel.





PITERPANZER
Visit this Community
Gdańsk, Poland
Joined: September 11, 2005
KitMaker: 314 posts
Armorama: 311 posts
Posted: Saturday, December 16, 2017 - 06:16 PM UTC
And continue today







My floor project is universal. You can choice version, and add caps and covers, remove some rivets . At this moment You can use chassi to early or late T34 or SU.
PITERPANZER
Visit this Community
Gdańsk, Poland
Joined: September 11, 2005
KitMaker: 314 posts
Armorama: 311 posts
Posted: Saturday, December 16, 2017 - 06:11 PM UTC
Short and late update.

After the rear transmition cover I did tensioning mechanism with the axis of the idler wheel.




PITERPANZER
Visit this Community
Gdańsk, Poland
Joined: September 11, 2005
KitMaker: 314 posts
Armorama: 311 posts
Posted: Saturday, December 16, 2017 - 06:10 PM UTC
Hull of SU and T34 are mostly ready.

Time to rework the chassi and I plan to do, that in spite of the differences I can adapt it to SU and T34.

The differences are in the position of escape hatch and 2 inspection caps.














PITERPANZER
Visit this Community
Gdańsk, Poland
Joined: September 11, 2005
KitMaker: 314 posts
Armorama: 311 posts
Posted: Friday, July 10, 2015 - 02:18 AM UTC
Yes sure, welcome.
I`ve got two versions of 500mm tracks.
18Bravo
Visit this Community
Colorado, United States
Joined: January 20, 2005
KitMaker: 6,046 posts
Armorama: 5,073 posts
Posted: Friday, July 10, 2015 - 02:06 AM UTC
Put me down for two sets of track. Do you take PayPal?
PITERPANZER
Visit this Community
Gdańsk, Poland
Joined: September 11, 2005
KitMaker: 314 posts
Armorama: 311 posts
Posted: Friday, July 10, 2015 - 01:41 AM UTC
New designed by my friend Michael SU85M was a good occasion to presentation new resin road wheels to T34 during modelers meeting. We plan to have most of road wheels and two drive sprocket and idler wheel. Michael use stamped road wheels to SU85 and me semispider road wheels to my T34. Please look at them and by the way on the new chassi roofand engine deck;-).






JPTRR
Staff MemberManaging Editor
RAILROAD MODELING
#051
Visit this Community
Tennessee, United States
Joined: December 21, 2002
KitMaker: 7,172 posts
Armorama: 2,193 posts
Posted: Friday, March 27, 2015 - 03:30 AM UTC
Piotr,

I am very happy to see 1/25 - 1/24 still progressing. Wonderful work you are doing. One day I hope to have that Bandai Tiger II complete!
CMOT
Staff MemberEditor-in-Chief
ARMORAMA
#406
Visit this Community
England - South West, United Kingdom
Joined: May 14, 2006
KitMaker: 10,258 posts
Armorama: 8,136 posts
Posted: Friday, March 27, 2015 - 02:27 AM UTC
Very nice work as always Piotr.
PITERPANZER
Visit this Community
Gdańsk, Poland
Joined: September 11, 2005
KitMaker: 314 posts
Armorama: 311 posts
Posted: Friday, March 27, 2015 - 12:50 AM UTC
In relation escaped me one episode.
Preparing early front girder and improve machine gun cover.
Aber`s fenders fit better every next step.










PITERPANZER
Visit this Community
Gdańsk, Poland
Joined: September 11, 2005
KitMaker: 314 posts
Armorama: 311 posts
Posted: Monday, March 16, 2015 - 03:01 AM UTC
It is time for the roof of the hull.
After the first steps, it looked as follow

By the way, I got 2 air vents


I knew that the next step will be to notch the whole floor slab and replacing it with a new, correct.



By the way, look at the painted and assembled tracks
PITERPANZER
Visit this Community
Gdańsk, Poland
Joined: September 11, 2005
KitMaker: 314 posts
Armorama: 311 posts
Posted: Monday, March 16, 2015 - 02:52 AM UTC
It was certain that it will not take long as I sit down to the table.
First I painted in 3 stages tracks to enjoy them.





Then I changed the front of tamiya`s late T34 performing early, semi-circular ram beam. (what is english name?)Edit is it "front girder"?




and corrected shape of machine gun cover


PITERPANZER
Visit this Community
Gdańsk, Poland
Joined: September 11, 2005
KitMaker: 314 posts
Armorama: 311 posts
Posted: Monday, March 16, 2015 - 02:41 AM UTC
In 2015
At first I receive from Aber PE fender to T34 and to SU85M/100.It`s rescaled, commersial version of his 1-35 kit.
New our resin tracks are much better then first and second version. Also some new details, periscope, resin engine deck, etc.


I still feels unsatisfied
PITERPANZER
Visit this Community
Gdańsk, Poland
Joined: September 11, 2005
KitMaker: 314 posts
Armorama: 311 posts
Posted: Monday, March 16, 2015 - 02:32 AM UTC
Hello again!
Six yeas ago I started one of my projects, conversion T34-85 from Tamiya to T34-76 hexagonal turret.It was very difficult, because nowhere You can get accessories to this scale. After some first steps i open my small forum`s shop for hobbyist like me.Step by step and now we have new line with resin accessories but, about it some words by the way.
In 2009
Resin hexagonal turre, commander cupola,new semi spider road wheels,smaller ring under turret,towing cables
