First Blood truck
namengr
Visit this Community
Illinois, United States
Joined: September 01, 2014
KitMaker: 332 posts
Armorama: 328 posts
Posted: Sunday, September 27, 2020 - 12:01 PM UTC
Evening all, was just watching First Blood and always wondered what model the National Guard truck was? The rear looks like an M-34 Beaver, but the cab is a hardtop with 5 windows. Can some of our truck experts tell me what it is? Might make an interesting dio project. Thanks, Wayne
Tank1812
Visit this Community
North Carolina, United States
Joined: April 29, 2014
KitMaker: 1,108 posts
Armorama: 885 posts
Posted: Sunday, September 27, 2020 - 12:21 PM UTC
GMC M135 according to these guys.
https://www.imcdb.org/vehicle_47899-GMC-M135-1951.html
Scalemates didn’t have a record for M135, so there might not be a kit for one.

HTH
agincajun
Visit this Community
South Carolina, United States
Joined: September 28, 2020
KitMaker: 10 posts
Armorama: 9 posts
Posted: Sunday, September 27, 2020 - 01:12 PM UTC
!!! New kid in class, there's no 1:35 scale kit of this truck unfortunately but looks like something ICM would be most capable at producing hint hint. I'm a fanatic for this period softskin and would love to see one molded someday.
covkid
Visit this Community
United Kingdom
Joined: March 13, 2015
KitMaker: 251 posts
Armorama: 193 posts
Posted: Sunday, September 27, 2020 - 04:28 PM UTC
Hi,

I have always liked these trucks and I would say your best starting point would be Monogram's M34.

The cargo bed and driveline appear to be the same. The only challenge would be the front clip

M35 kits are not suitable as they use Rockwell axles.

regards jason
Kevlar06
Visit this Community
Washington, United States
Joined: March 15, 2009
KitMaker: 3,670 posts
Armorama: 2,052 posts
Posted: Sunday, September 27, 2020 - 05:47 PM UTC
I’ve always liked the looks of the “round nosed jimmy” as the M135 is known. It was supposed to be the replacement for the CCKW, but was only produced for about 5 years between 1950 and 1955, and was supplanted by the M35 series. It had single wheels at the rear, as opposed to duals of the CCKW, and an automatic transmission. It primarily ended up in the National Guard and Reserves, but most especially with the Canadian Army. I rode in one that belonged to the Princess Patricia Regiment of the Canadian Army at Fort Lewis in 1981. They were also in service with some NATO countries into the late 80s. As was mentioned above, as far as I know, nobody makes one in 1/35, but I think Rocco or somebody made one in 1/87.
VR, Russ
Frenchy
Visit this Community
Rhone, France
Joined: December 02, 2002
KitMaker: 12,718 posts
Armorama: 12,506 posts
Posted: Sunday, September 27, 2020 - 09:14 PM UTC
On a side note, the M211 was identical to the M135 except it had a dual-wheel tandem and smaller 9:00x20 tires :


Old related thread

1/48th scale diecast M135 from HartSmith Models :



H.P.
RobinNilsson
Staff MemberTOS Moderator
KITMAKER NETWORK
Visit this Community
Stockholm, Sweden
Joined: November 29, 2006
KitMaker: 6,687 posts
Armorama: 5,556 posts
Posted: Sunday, September 27, 2020 - 11:59 PM UTC
http://www.alfaheaven.com/MilitarySection/6x6%20Trucks/M135.html
The technical stuff ...
18Bravo
Visit this Community
Colorado, United States
Joined: January 20, 2005
KitMaker: 7,219 posts
Armorama: 6,097 posts
Posted: Monday, September 28, 2020 - 01:36 AM UTC

Quoted Text

Hi,

I have always liked these trucks and I would say your best starting point would be Monogram's M34.

The cargo bed and driveline appear to be the same.



It would take bit of work. The cargo bed in fact has cutouts over the rear wheels you'd need to fix.

On a side note - when you spend as much time in the woods as I do, you're bound to find something cool once in a while...


RobinNilsson
Staff MemberTOS Moderator
KITMAKER NETWORK
Visit this Community
Stockholm, Sweden
Joined: November 29, 2006
KitMaker: 6,687 posts
Armorama: 5,556 posts
Posted: Monday, September 28, 2020 - 03:00 AM UTC




Two different types of cutouts?
Frenchy
Visit this Community
Rhone, France
Joined: December 02, 2002
KitMaker: 12,718 posts
Armorama: 12,506 posts
Posted: Monday, September 28, 2020 - 03:12 AM UTC
I guess the bottom one may be the Canadian M135CDN version (built by General Motors of Canada)...

Looks like the cutout is the same in both cases but the Canadian version has extra metal strips welded on :



...Or maybe these are not specific to the Canadian version

H.P.
barkingdigger
Staff MemberAssociate Editor
ARMORAMA
#013
Visit this Community
England - East Anglia, United Kingdom
Joined: June 20, 2008
KitMaker: 3,977 posts
Armorama: 3,400 posts
Posted: Monday, September 28, 2020 - 03:28 AM UTC
Can't see any difference between the Monogram bed and the Rambo pics, so it should be a good start - you'll still need a new cab, hood, and fenders though.

@Robin, are we talking about that straight-cut wheel arch in the bed? The colour pic with the "angled" cutout just has two strips added presumably to strengthen the bed at the corners of the wheel arch.
HeavyArty
Visit this Community
Florida, United States
Joined: May 16, 2002
KitMaker: 17,690 posts
Armorama: 13,739 posts
Posted: Monday, September 28, 2020 - 04:12 AM UTC
From the Tech page that Robin linked to, it looks as though it still had the CCKW axles and suspension, the same bed and wheel/tire combo (11:00x20) as the M34, and a new cab. Based on that, you would need a CCKW kit, M34 kit, and to scratch the cab, hood, fenders, front bumper, fuel tank, spare tire carrier, etc., etc.. Maybe someone with CAD and GM truck experience could do some 3-D conversion parts? Tom??
barkingdigger
Staff MemberAssociate Editor
ARMORAMA
#013
Visit this Community
England - East Anglia, United Kingdom
Joined: June 20, 2008
KitMaker: 3,977 posts
Armorama: 3,400 posts
Posted: Monday, September 28, 2020 - 04:51 AM UTC

Quoted Text

From the Tech page that Robin linked to, it looks as though it still had the CCKW axles and suspension, the same bed and wheel/tire combo (11:00x20) as the M34, and a new cab. Based on that, you would need a CCKW kit, M34 kit, and to scratch the cab, hood, fenders, front bumper, fuel tank, spare tire carrier, etc., etc.. Maybe someone with CAD and GM truck experience could do some 3-D conversion parts? Tom??



Hmm. The drivetrain needs replaced with "banjo" axles, and it looks like the springs are different to either CCKW or M34 parts, so they need redone too. CAD-ing the cab and hood could be done, but it'd take time and is not at the top of my list at the moment. I must say I'm surprised there isn't one in resin yet, let alone plastic! Maybe I'll look at it as a winter project...
Northwoods
Visit this Community
United States
Joined: May 13, 2019
KitMaker: 22 posts
Armorama: 23 posts
Posted: Monday, September 28, 2020 - 09:48 AM UTC
1/48 Scale

http://www.asam.co.uk/mmgmcm.html
RobinNilsson
Staff MemberTOS Moderator
KITMAKER NETWORK
Visit this Community
Stockholm, Sweden
Joined: November 29, 2006
KitMaker: 6,687 posts
Armorama: 5,556 posts
Posted: Monday, September 28, 2020 - 05:19 PM UTC
Frenchys image explained the angled cutout thing.
barkingdigger
Staff MemberAssociate Editor
ARMORAMA
#013
Visit this Community
England - East Anglia, United Kingdom
Joined: June 20, 2008
KitMaker: 3,977 posts
Armorama: 3,400 posts
Posted: Monday, September 28, 2020 - 10:44 PM UTC
There are a number of scale drawings of M135/M211 variants in back issues of Tankette, the in-house magazine for MAFVA members. I've got a few, but I believe PDF copies are orderable by paid-up MAFVA members through the MAFVA website. These would go a long way towards helping anyone attempting a conversion.

Issues: 14/1, 26/4, 29/4, 34/2, 36/6
barkingdigger
Staff MemberAssociate Editor
ARMORAMA
#013
Visit this Community
England - East Anglia, United Kingdom
Joined: June 20, 2008
KitMaker: 3,977 posts
Armorama: 3,400 posts
Posted: Wednesday, September 30, 2020 - 08:35 AM UTC
Just found this on Shapeways:

https://www.shapeways.com/product/6Y4XD3MWC/1-35-scale-m135-cab?optionId=167492789&li=shops

It's a 1:35 M135 hood, fender, and cab set. But it's a bit lumpy & crude - I suspect the designer started with his 1:100 set and scald it up without refining it. And it's only available in the more grainy nylon plastics.
Frenchy
Visit this Community
Rhone, France
Joined: December 02, 2002
KitMaker: 12,718 posts
Armorama: 12,506 posts
Posted: Wednesday, September 30, 2020 - 08:51 AM UTC
I'm sure you would do much better Tom

H.P.
chrisgrove
Visit this Community
England - South East, United Kingdom
Joined: October 13, 2006
KitMaker: 78 posts
Armorama: 75 posts
Posted: Sunday, November 29, 2020 - 09:45 AM UTC

Sorry to hear that there is no 1/35 kit of the M135 (I disregard that awful cab), but you are not the only ones. Braille Scale offers no kits either as far as I can find out. Did many a mile in one of those, both (Canadian) ones at Gagetown and (British, ex Canadian) at BATUS. I did wonder if they had springs! I did a 1/76 scale drawing for Tankette (Vol 14/1) many moons ago, but the back of the front bumper should be straight, not angled as I drew it
Chris
